| FRAME |
ALUXX SL-grade aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, ‘Boost’ 148x12mm, Universal Derailleur Hanger |
| FORK |
RockShox Domain R 29er, 170mm travel, 15×110 Boost, Maxle Stealth, E-bike Approved |
| REAR SHOCK |
Fox Float DPS Performance, EVOL Large Volume sleeve, 2-position lever, 205×62.5mm Trunnion mount, custom tuned |
| BOTTOM BRACKET |
n/a |
| STEM |
Giant Contact SL 35 |
| SADDLE |
Giant Romero Trail |
| SEATPOST |
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170) |
| PEDALS |
Flat pedal |
| GRIPS |
Giant Tactal Pro-E, single lock-on |
| REAR DERAILLEUR |
Shimano Deore 12-speed |
| FRONT DERAILLEUR |
MRP 1X HD2 custom co-molded chain guide |
| CRANK |
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165) |
| SHIFTERS |
Shimano Deore |
| CASSETTE |
Shimano Deore CS-M6100-12, 10-51T, 12-speed |
| CHAIN |
KMC e.12 Turbo, EcoProteq, e-bike optimized |
| BRAKES |
Shimano Deore BR-M420, 4-piston, hydraulic disc, 203mm |
| BRAKE LEVERS |
Shimano Deore, I-spec EV |
| RIMS |
Giant AM 29″ [F] 27.5″[R], Tubeless ready, 30mm inner width |
| SPOKES |
Sapim E-Lite [R] Race [F], e-bike optimized |
| FRONT HUB |
Shimano MT410 Boost, Center-Lock, [F] 110×15 [R] 148x12mm Micro-Spline Drive Body Thru-axle |
| REAR HUB |
Shimano MT410 Boost, Center-Lock, [F] 110×15 [R] 148x12mm Micro-Spline Drive Body Thru-axle |
| TIRES |
Maxxis Minion DHF 29×2.6″ foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5×2.5″ foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R] |
| MOTOR |
Giant AM 29″[F] 27.5″[R], Tubeless ready, 30mm inner width |
| HUBS |
SyncDrive Pro, 85Nm, powered by Yamaha |
| BATTERY |
EnergyPak Smart 800,EnergyPak Plus range extender compatible (exclude S Size) |
| REMOTE |
Wireless display compatible |
