| FRAME |
FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel |
| FORK |
FOX FLOAT 36 Performance Elite, GRIP2 damper, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel |
| REAR SHOCK |
FOX FLOAT X Performance Elite, Rx Trail Tune, EVOL Air sleeve, 2-position lever w/ LSC adjustment, S1:210x50mm, S2-S6:210x55mm |
| BOTTOM BRACKET |
SRAM DUB, BSA 73mm, Threaded |
| STEM |
Alloy Trail Stem, 35mm bar bore |
| HANDLEBAR |
Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp |
| SADDLE |
Bridge Comp, Hollow Cr-mo rails, 155/143mm |
| SEATPOST |
OneUp, Dropper Post-V2, MMX lever, 34.9 (S1:120mm, S2/S3:150mm, S4: 180mm, S5/S6: 210mm) |
| GRIPS |
Deity Grips |
| REAR DERAILLEUR |
SRAM GX Eagle AXS, w/ battery cover |
| CRANK |
SRAM GX Eagle Alloy, DUB, 165/170/175mm, 32t, 32T |
| SHIFTERS |
SRAM GX Eagle AXS Controller |
| CASSETTE |
SRAM XG-1275, 12-speed, 10-52t |
| CHAIN |
SRAM GX Eagle, 12-speed |
| BRAKES |
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline |
| RIMS |
Roval Traverse 29 Alloy, 30mm inner width, hand-built, 2Bliss Ready |
| SPOKES |
DT Swiss Competition Race |
| FRONT HUB |
Roval, sealed cartridge bearings, 15x110mm spacing, 28h |
| REAR HUB |
Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h |
| TIRES |
Front: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29×2.3″, Rear: Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 29×2.3″ |
